Bocube Alu | Enclosure with smooth lid, light grey, hinged
BA 180809-7035

Manufacturer No 00114135
Material cast alloy
IP 66,68,69
Dimensions 199  x  86  x  90 mm
Product Drawing
Technical Drawings
    CAD Files
    Assemblies

      Product Specs

      A

      199

      B

      86

      C

      90

      a1

      -

      a2

      155,5

      b1

      -

      b2

      77,5

      c1

      83,5

      Colour

      Light grey

      Enclosure material

      cast alloy

      Artikel_Farbe

      Light grey, similar to RAL 7035

      Artikel_IP_Nummer

      66,68,69

      Artikel_IK_Nummer

      07,08

      Assembly Instructions

      Bocube-Alu_BA_Gehaeusemontage_Enclosure_Assembly_00911501.pdf (1.5 MB)

      Material Data

      AlSi12 Legierung (Cast material)
      AluProfil Legierung (Profile material)
      DB Beschichtung Brillux 5903 (Powder coating)
