BS 200 DI-D-5005 Decor seals
Decor seals
BS 200 DI-D-5005
Order No:
82825005 Manufacturer No: 82825005
Technical Drawings
82825005_BS-200-DI-D-5005.pdf
82825005_BS-200-DI-D-5005.pdf
(180.2 KB)
82825005_BS-200-DI-D-5005.dxf
82825005_BS-200-DI-D-5005.dxf
(2.8 MB)
Product Information
BOS-Streamline_GB.pdf
(2.9 MB)
Product Specs
Color of enclosure group
Signal blue
Enclosure Material
ABS, decor seal made of TPE; for details see Technical Information
Scope of delivery
Decor seal, 4 screws; BS 200 DI-D-… 1 screw
Note
Not for use with BS .02 and BS .04.
Assembly Instructions
Do you have questions about this product?
Important!
To compensate for pressure when temperatures change and cause moisture in the enclosure, we we recommend that you use a pressure compensation element.
