BTK 5.0-Starter-Kit BoTouch Plastic Starter kit (black, similar to RAL 9005)
BoTouch Plastic Starter kit (black, similar to RAL 9005)
BTK 5.0-Starter-Kit
Order No:
78010505.MT1 Manufacturer No: 78010505.MT1
Dimensions
166 x 116 x 52.5 mmProduct Information
Product Specs
Color of enclosure group
Black, similar to RAL 9005
Protection class
IP 65
Enclosure Material
Rear hood: galvanised sheet steel
Rear panel: anodized aluminium
BTK enclosure frame: PC UL 94 V0
BTK-IP enclosure frame: PA 6.6 GF 30 UL 94 V0
BTA front frame: aluminium (anodized or powder-coated)
Scope of delivery
– 1 front frame, 1 aluminium mounting panel (2 mm)
– 1 glass pane incl. single-color printing (black, similar to RAL 9005)
– 1 display G-ET… fully-mounted using optical bonding process with display retaining plate
– 1 rear hood
Note
These are manufactured as customer and application-specific test models which specialists intend to use only in research and development facilities for these purposes.
Material Data
PC Lexan505RU (Front frame)
PA 66 FRIANYL A3 V0GF30 (Clamps)
Do you have questions about this product?
Important!
To compensate for pressure when temperatures change and cause moisture in the enclosure, we we recommend that you use a pressure compensation element.
» Additional information
